07 Using Zones to Manage Incoming Traffic Depending on Source IP or IP Mask or Network | #linuxtopic

How to Allow source IP or source network in firewall,

We can use zones to oversee approaching traffic dependent on its source. you add a source to a zone, the zone becomes dynamic and any approaching traffic from that source will be coordinated through it.

If we want to route incoming traffic into a specific source, we will add the source to that zone. The source can be an IP address or Network/IP mask in the Classless Inter-domain Routing (CIDR) notation.

List all available zones:

firewall-cmd --get-zones

List allowed sources

firewall-cmd  --list-sources

List allowed sources for the required zone:

firewall-cmd --zone=linuxtopic --list-sources

To add source IP in the current zone

firewall-cmd --add-source=192.168.100.100/32

To add source  IP mask or network in the current zone

firewall-cmd --add-source=192.168.100.0/24

To remove  source  IP / IP mask or network in the current zone

firewall-cmd --remove-source=192.168.100.0/24

firewall-cmd --remove-source=192.168.100.100/32

To set the source IP address or IP mask / Network for a specific zone:

firewall-cmd --zone=linuxtopic --add-source=192.168.200.1/32

firewall-cmd --zone=linuxtopic --add-source=192.168.200.0/24

To make the new settings persistent

firewall-cmd --runtime-to-permanent

We make all settings permanent to verify we restart service and checked, all added sources was enabled on linuxtopic zone.

To remove the source IP address or IP mask / Network for a specific zone:

firewall-cmd --zone=linuxtopic --remove-source=192.168.200.1/32

firewall-cmd --zone=linuxtopic --remove-source=192.168.200.0/24

To permanently remove

firewall-cmd --zone=linuxtopic --remove-source=192.168.200.1/32 --permanent

firewall-cmd --zone=linuxtopic --remove-source=192.168.200.0/24 --permanent

Thanks
